| Model | LAHR14-BPZAD | LAHR16-BPZAD | LAHR16-BPZAS | LAHR19-BPZAD | LAHR19-BPZAS | LAHR22-BPZAS | LAHR28-BPZAS | LAHR32-BPZAS | ||
| 5P-220V | 6P-220V | 6P-380V | 7P-220V | 7P-380V | 8P | 10P | 12P | |||
| Cooling | Cooling capacity | Ambient temp 35ºC/ outlet water temp 7 ºC(kW) | 12.3 | 14 | 14 | 15.5 | 15.5 | 21 | 25.5 | 30 |
| Power input | kW | 4.4 | 5.1 | 5.1 | 5.7 | 5.7 | 7.3 | 8.9 | 10.5 | |
| COP | 2.8 | 2.75 | 2.75 | 2.72 | 2.72 | 2.88 | 2.87 | 2.86 | ||
| Heating | Heating capacity 1 | Ambient temp 7ºC/ outlet water temp 45ºC(kW) | 17 | 18 | 18 | 19 | 19 | 22.5 | 28 | 34 |
| Power input | kW | 4.4 | 5.1 | 5.1 | 5.4 | 5.4 | 6.7 | 8.3 | 10.3 | |
| COP | 3.54 | 3.53 | 3.53 | 3.52 | 3.52 | 3.36 | 3.37 | 3.3 | ||
| Heating capacity 2 | Ambient temp -12ºC/ outlet water temp 41ºC(kW) | 11.3 | 12.5 | 12.5 | 13.7 | 13.7 | 15.5 | 20.3 | 23 | |
| Power input | kW | 4.5 | 5 | 5 | 5.5 | 5.5 | 6.1 | 8.2 | 9.1 | |
| COP | 2.51 | 2.5 | 2.5 | 2.49 | 2.49 | 2.54 | 2.48 | 2.53 | ||
| Heating capacity 3 | Ambient temp -20ºC/ outlet water temp 41ºC(kW) | 10 | 10.8 | 10.8 | 12.2 | 12.2 | 14.5 | 16.9 | 20.50 | |
| Power input | kW | 4.7 | 5.1 | 5.1 | 5.6 | 5.6 | 6.7 | 7.8 | 9.535 | |
| COP | 2.13 | 2.12 | 2.12 | 2.18 | 2.18 | 2.16 | 2.17 | 2.19 | ||
| Max. input power/current | kW / A | 6.0/28.2 | 7/33.6 | 7/12.8 | 7.3/34.5 | 7.3/14.8 | 9.5/16 | 12.3/22 | 15/26 | |
| IPLV(C)/IPLV(H) | 4.0/3.2 | 4.0/3.2 | 4.0/3.2 | 4.0/3.2 | 4.0/3.2 | 4.0/3.2 | 4.0/3.2 | 4.0/3.2 | ||
| Water side resistance | kPa | 25 | 26 | 26 | 28 | 28 | 35 | 40 | 42 | |
| Circulating water flow | m³/h | 2.12 | 2.41 | 2.41 | 2.67 | 2.67 | 3.61 | 4.39 | 5.2 | |
| Inlet and outlet pipe specifications | Rc1″ | Rc1″ | Rc1″ | Rc1″ | Rc1″ | Rc1-1/4″ | Rc1-1/4″ | Rc1-1/4″ | ||
| Max. working pressure on water side | MPa | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | |
| Exhaust/suction side allowable working pressure |
MPa | 4.15/1.5 | 4.15/1.5 | 4.15/1.5 | 4.15/1.5 | 4.15/1.5 | 4.15/1.5 | 4.15/1.5 | 4.15/1.5 | |
| High/low side Max. allowable pressure |
MPa | 4.15/1.5 | 4.15/1.5 | 4.15/1.5 | 4.15/1.5 | 4.15/1.5 | 4.15/1.5 | 4.15/1.5 | 4.15/1.5 | |
| Anti electric shock protection category/waterproof level | Class I / IPX4 | Class I / IPX4 | Class I / IPX4 | Class I / IPX4 | Class I / IPX4 | Class I / IPX4 | Class I / IPX4 | Class I / IPX4 | ||
| Noise | dB(A) | ≤56 | ≤58 | ≤58 | ≤60 | ≤60 | ≤59 | ≤60 | ≤60 | |
| Refrigerant / charged | kg | R410A/3.2 | R410A/3.2 | R410A/3.2 | R410A/3.2 | R410A/3.2 | R410A/4.8 | R410A/5.8 | R410A/5.8 | |
| Dimensions | mm | 1040*420*1360 | 1040*420*1360 | 1040*420*1360 | 1040*420*1360 | 1040*420*1360 | 1140*420*1560 | 1140*420*1560 | 1140*420*1560 | |
| Weight | kg | 132 | 135 | 138 | 137 | 140 | 185 | 194 | 202 | |
